CE & EPA Certification 0.6 Ton Hydraulic Rubber Crawler Micro  Excavator Mini  Excavators

Compact. Powerful. Versatile micro excavator mini excavators

Equipped with a robust 8.5 HP petrol engine from TRIDENT and precise hydraulics, it ensures maximum efficiency and productivity. Thanks to its maneuverability and easy operation, it enables precise work even in demanding environments.

Product Specifications

TECHNICAL DATA: Petrol engine: Trident TR306(E) 306cc, 8.5 HP, 6.5 kW (complies with the latest EU environmental directive) Starter petrol engine: electric starter Swivel range: 360 degrees Swivel range of excavator arm: approx. 70 degrees left, 70 degrees right Overloading height: max. 1350 mm Ejection height: max. 2100 mm Digging depth: max. 1200 mm Reach: max. 2330 mm Total width with mirror: 770 mm Total width without mirror: 700 mm Track width: 690 mm Maximum height: 1585 mm from floor to top edge of mirror Minimum height: 1305 mm from floor to top edge of seat (with mirrors removed) Load capacity (fully extended excavator arm): approx. 140 kg (dozer blade bottom) Load capacity (full extension of excavator arm): approx. 80 kg (dozer blade above) Tearing force: approx. 450 kg Gradeability: max. 18 degrees Weight: approx. 562 kg Shipping dimensions: approx. 2275x740x1285 mm (LxWxH) Weight when shipping: approx. 685 kg MISCELLANEOUS: Complete set: incl. 30 cm & 50 cm excavator shovels and a gripper Electric starter: 12 volts Battery level indicator Petrol tank capacity: 6 liters Oil tank “floating” mounted Swivel radius: 360°SPECIAL FEATURES: High-quality and robust workmanship Easy to handle Transport on a trailer or in a van possible Can be driven through conventional doors (excavator is 700 mm wide) Various attachments included Powerful Hydraulic pump unit Hydraulically lowerable dozer blade Load capacity of approx. 80 to 140 kg (depending on the position of the excavator arm) LED work lights All lubrication points easily accessible
